F3 Fusion Table Saw – 3HP – 1PH – 220V

Step up your shop’s cutting power with the Laguna F3 Fusion Table Saw. Built for serious woodworkers, this machine delivers precision and performance with a robust 3HP motor and smooth-running 220V operation. Whether you’re ripping hardwoods or making fine cuts in sheet goods, the F3 Fusion ensures every pass is clean, stable, and reliable.

The Fusion F3 table saw is built with no compromises. This heavy-duty cabinet saw features a 3HP/220V motor for all your wood cutting needs. It has permanently lubricated bearings and Acme screws on the inside and a precision-ground cast iron table with cast iron upper and lower trunnions mean this saw is built to last from the inside out. Precision-ground cast iron table wings and 14-gauge steel cabinet complete the package. An integrated dust collection keeps your work surface clear by utilizing dust collection over and under the blade along with a sealed base. A digital readout allows for precise blade tilt adjustment and the fence features a Hi/Low window for easy set-up and accurate cuts. This table saw has an on-board tool storage system keeps all the accessories including the industrial Fusion fence, European Hi-Lo fence, miter gauge and push stick neatly stowed when not in use. While the built in mobile base allows you to move and store your saw wherever you need it.

Features:

• Ensures every pass is clean, stable, and reliable.
• Cast iron table for rock-solid stability and smooth feed
• Precision fence system for accurate, repeatable cuts
• Integrated dust collection for a clean and efficient operation
• A digital readout allows for precise blade tilt adjustment
• Fence features a Hi/Low window for easy set-up and accurate cuts.

Specifications:

• Motor: 3 HP/220V/TEFC Capacitor Start Induction with Poly-V Belt Drive
• Motor Speed: 3450 RPM
• Starter Switch: Magnetic
• Rip Capacity: 36″
• Blade Size: 10″
• Vertical Cut Height: 3-1/8
• Cut Height at 45: 2-1/8″
• Blade Tilt: 0-45 Left
• Minimum Kerf: 3mm ~1/8″ (actual: 0.1875″)
• Maximum Kerf (Dado Blade): 13/16″
• Arbor Speed: 4500 RPM
• Arbor Diameter: 5/8″
• Miter Slot: 3/4″ to 1″ T-slot
• Throat Plate: Zero Clearance Square Die-Cast, w/adjustment
• Fence: Double Rail Cam Action
• Base Size: 18-5/8″ L x 19-1/4″ W
• Floor to Table Height: 34-3/4″
• Table Size: 27″L x 20″ W
• Extension Wing: 27″L x 12″ W (x2)
• Throat Plate Size: 14-5/8″ L x 4-1/16″ W x 1/2″ T
• Dust Port Size: 3-7/8″ OD
• CFM Requirement: 400 CFM
• Overall Size: 39-3/4″ L x 65-5/8″ W x 38″ H
• Machine Weight: 385 lb.
• Shipping Weight: 482 lb.
• Shipping Dimensions: 29-3/4″ L x 46-5/8″ W x 42-5/8″ H
• Warranty: 2 year

Electrical Specifications:

• Power Requirements: 220V-1PH-60HZ
• Amperage (FLA): 15 AMP (220V)
• Plug Included: 6-15
• Circuit Breaker Required: 220V – 25 AMP
• Receptacle Required: 6-15

What’s Included:

• (1) Laguna Fusion F3 Table Saw, (1) Outfeed Table Attachment, (1) Right Wing Table, (1) 10 x 60T Saw Blade, (1) European Hi-Lo Fence, (1) Industrial Fusion Fence, (1) Dust Collection Guard, (1) Premium Miter Gauge, (1) Blade Guard, (1) Arbor Wrench, (1) Riving Knife, (1) Push Stick, (1) Blade Changing Tool and (1) Premium Zero Clearance Throat Plate.
